Λεπτομέρειες:
|
| Υλικό: | Ενωμένη στενά ακτίνα Χ, καυτή - κυλημένη ακτίνα Χ, purlin C/Z | Επιφανειακή επεξεργασία: | Alkyd εγχυτήρας 80um |
|---|---|---|---|
| Πόρτα: | πόρτα κυλίνδρων, συρόμενη πόρτα | Παράθυρο: | Διπλό γυαλί κραμάτων αργιλίου |
| Χωρητικότητα γερανού: | 5 ~ 30TONS | Φορτίο αιολικής ενέργειας: | Ανώτατο 280KM/h |
| Επισημαίνω: | Q355B Material Steel Structure Warehouse,5~30Tons Crane Capacity Steel Structure Warehouse,Max 280KM/h Wind Load Steel Structure Warehouse |
||
| Items | Specification |
|---|---|
| Main Steel Frame | Column: Q355B Welded H Section Steel Beam: Q355B Welded H Section Steel |
| Secondary Frame | Purlin: Q235B C and Z purlin Knee brace: Q235B Angle Steel Tie Rod: Q235B Circular Steel Pipe Brace: Q235B Round Bar |
| Vertical and Horizontal Support | Q235B Angle Steel, Round Bar or Steel Pipe |
| Maintenance system | Roof Panel: EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet Wall Panel: Sandwich Panel / Corrugated Steel Sheet |
| Accessories | Window: Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window Door: Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door Rainspout: PVC |
| Live load on Roof | 120kg/Sqm (Color steel panel surrounded) |
| Wind Resistance Grade | 12 Grades |
| Earthquake-resistance | 8 Grades |
| Structure Usage | Up to 50 years |
| Temperature | Suitable temperature: -50°C to +50°C |
| Certification | CE, SGS, ISO9001:2008, ISO14001:2004 |
| Finishing Options | Vast array of colors and textures available |
| Paint Options | Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized |
